Gallery

Many examples of past production work can be seen on this page, along with a brief description.
All images displayed on this website show internal products, or products released with permission from the owner. No confidential information is shown.


Outdoors and sporting equipment
Barrel bores Stainless cam lever spools Internally-ported grip frames (top view) Paintball marker bodies Snatchgrips with reduced-diameter cap screws (anodized) Tool-free removal knobs Unmilled body blanks prior to finishing Compound archery bow cam with adjustable tension points Tank adapter housing Tank air source drop forwards with internal porting 4-axis feedneck compression bodies Trigger guards Multi-bore/multi-length reverseable barrel system Single triggers using dual-bearing pivot points Grip wraparound die set Spring-loaded detent plungers Spring-loaded detent housings

Camera and cellphone components
Engraved swivel tube brackets Slide rail mounting attachments V-clamp mount housings Camera lens captive bezel caps Projector gear replacement Phone case frames Crocodile cover plates Tripod tilting camera mount

Fluid power; hydraulics and pneumatics
Pneumatic locking adapter coupler housings Breakout adapters for tapered pipe thread fittings Aluminum cross-ported pressure couplings Adapter pin-valve shutoff knobs Bolt guide endcaps Pressure-compensating regulator cores Fluid dump valve pistons Tank standard adapters Valve endcaps Wind power planetary gear mount Cam valve actuator knobs Adjustable regulator housings

Artistic
Spinal bone cosmetics 5-axis machined chess knight 4-axis machined fire cosmetics Billet machined salt/pepper grinders 5-axis machined spike ball Stanley cup 1:17 scale miniature Motorcycle stand bases Alien plant Turners cube Wedding cake topper

Electronics
Grip extender circuit board mounting brackets Sensor PCB mounting blocks Circuit board extension covers Billet machined metal switch levers Imbedded pressure sensor manifolds

Robotics and automation
Robotics staging fixture Robotics staging fixture Robotics staging fixture Robotics staging fixture Precision wave shape jig plate

Vehicle components
5-axis belt drive transmission housing Billet-machined uprights to repalce cast components 5-axis axle bearing uprights Motorcycle triple trees CVT transmission spring plate 4-axis transmission housing Transmission balance plate

CNC engraving
1/16" ball engraving through anodizing (0.003" deep) 1/16" ball engraving through anodizing (0.010" deep) 1/16" ball engraving (0.015" deep) 1/32" ball engraving (0.0025" deep) 1/32" ball engraving (0.015" deep) 1/32" ball engraving (0.025" deep)
Note: we also offer laser engraving on anodized surfaces.

Laser-cut items
Foamies Retainer caps (polycarbonate)
